Back by popular demand, the
Plasmasonic boards are here to stay.
These boards utilize full CW type
modulation which can audio modulate
a SSTC to create near perfect audio
quality. This is the second
generation Plasmasonic, as featured
in the numerous videos seen on
YouTube, which includes an onboard
10-step LED VU meter. Use one
for mono operation, or really make
heads spin with full stereo
operation utilizing two (2) SSTCs.
(Note: Photo above is first
generation board without the VU
meter) Does not include
components.
For the largest of the DRSSTC
systems, a high power isolated gate
driver board with onboard isolated
power supplies are required for
operation with the mighty CM600 IGBT.
This board provides onboard isolated
+20V/-10V power supplies which are
used to provide a high current and
bias drive to the large CM600 IGBT
bricks. Screws directly to the
CM600 IGBT brick. Does not include
components.
The XenoSonic II is a highly
advanced, out of this world, musical
interface for your solid state or
vacuum tube based Tesla coil.
It converts the audio input from
your keyboard, guitar, or other
instrument, to a pulsewidth
controlled audio modulation signal
that is then sent to your Tesla coil
to produce musical tones.
The miniBrute DRSSTC Tesla system,
which is featured in the book,
DRSSTC: Building the Modern Day
Tesla Coil, is
a small two foot system specially
designed to pack the biggest
punch in the smallest package. At only 2
feet high, it easily produces output
arcs exceeding 3 feet in length.
And when used in conjuction with the
Advanced Modulator, this DRSSTC is
capable of creating a wide array of
effects including burst modes,
single shot mode, long pulse mode,
and an infinite number of other
effects with continously variable
pulsewidth and PRF parameters.
For the first time ever, we are
offering board kits of this design
so that you can easily design and
build your own miniBrute DRSSTC system.
We will be continuing to update this
site frequently in the next few
weeks adding many photos and
videos. Schematics and parts lists
will be added as well.
miniBrute
DRSSTC Board Kit (Available Now)
The most popular kit, this includes
all (7) DRSSTC boards which were
used in our miniBrute system. This
includes Current Transformer Board,
Controller Board, Fault / Status /
Current Meter Board, MMC Board,
Rectifier Board, Power Board, and
several LED illumination boards. (Bareboards
only)
The miniBrute Advanced Modulator
board is an all-in-one external
interrupter board for your DRSSTC
which produces an infinite variety
of effects. Effects include
single-shot mode, long-pulse mode,
burst mode, and continous mode with real-time
adjustable duty cycle and pulsewidth,
and several other features.
This kit features the machined and
silkscreened front and rear panels
used in the miniBrute system.
They are designed to be used
directly with the miniBrute DRSSTC
board kit
above.
Available in anodized red, blue,
green, and black. The name in
the upper left of the front panel
can be customized with your own text
and custom color at no extra cost.
Allow 3 weeks for delivery.
Complete Panel Package $149.99
Advanced
Modulator Panel (Available
Now)
This kit features the machined and
silkscreened front panel
used for the Advanced Modulator. Available in
anodized red, blue, green, and
black. The name in the upper
left of the front panel can be
customized with your own text and
custom color at no extra cost.
Allow 3 weeks for delivery.
Complete Panel Package $129.99
ORDER RESTRICTIONS:
Due to the nature of these custom
boards and panels and the fact that
they may be manufactured separately
per your order, no refunds will be
issued. Defective boards and
panels will be replaced at no
charge.
